The Deutz-Fahr C7205 TS is a well-rounded combine harvester that offers a powerful engine, efficient threshing and separation systems, and a comfortable, well-equipped cab. It is an excellent choice for farmers looking for a reliable and versatile machine capable of handling diverse harvesting tasks. Its advanced features, coupled with ease of operation, make it a valuable asset in modern agriculture.
Equipped with a Mercedes Benz OM936 engine, the C7205 TS provides substantial power, with a rated output of 310 hp. This engine, compliant with Tier 4 Final emissions standards, not only delivers strong performance but also adheres to stringent environmental regulations. The six-cylinder diesel engine ensures efficient fuel consumption and a reliable power source for various harvesting conditions.
The combine harvester measures 9.24 meters in length, 3.29 meters in width, and 3.99 meters in height, weighing in at 16.3 t. These dimensions contribute to its stability and operational efficiency in various field conditions.
The Deutz-Fahr C7205 TS excels in its threshing and separation capabilities. The combine features a 600 mm diameter threshing drum with eight rasp bars, facilitating effective threshing and gentle handling of crops. The inclusion of a turbo separator further enhances its productivity by increasing separation efficiency. The machine's ability to maintain a consistent pitch angle and the presence of a stone trap highlight its design focus on both efficiency and safety.
Although specific details about the total ventilated sieve area and fan type are not provided, the combine's cleaning system is engineered to ensure optimal grain separation and cleanliness.
The grain tank has a capacity of 8500 liters, allowing for extended operation before unloading. The header offers flexibility with options suitable for different crops, featuring a cutting width of 7.2 meters to maximize harvesting efficiency.
The C7205 TS is equipped with 650/75 R32 front tires and 405/70 R20 rear tires, providing excellent traction and stability. The hydrostatic transmission offers four forward gears, enabling speeds up to 26 km/h, suitable for various field conditions.
The Commander Cab V offers a comfortable and ergonomic environment for the operator, featuring an adjustable seat, a comprehensive display, and integrated camera systems to enhance operational safety and efficiency. The cab is designed to minimize noise levels, providing a quieter working environment.
Deutz-Fahr C7205 TS Specifications
Engine |
|---|
| Type |
Mercedes Benz OM936 |
| Rated Power |
310 hp/228 kw |
| Displacement (cu in/l) |
369/6.1 |
| Rated RPM |
2200 |
| Cylinders |
6 |
| Fuel Type |
Diesel |
| Emissions |
Tier 4 Final |
Dimension |
|---|
| Length |
9.24 m |
| Width |
3.29 m |
| Height |
3.99 m |
| Wheelbase |
3.89 m |
| Weight |
16.3 t |
Threshing and Separations |
|---|
| Threshing Drum Width |
1270 mm |
| Threshing Drum Diameter |
600 mm |
| Threshing Drum Rasp Bar |
8 |
| Electrical variator |
420-1250 rpm |
| Pitch Angle |
121° |
| Concave Separation Surface |
0.95 m² |
| Concave Rasp Bars |
15 |
| Turbo Separator Diameter |
590 mm |
| Turbo Separator Rate |
775/410 rpm |
| Walkers Number |
5 |
| Steps Number |
4 |
| Shaking Surface Area |
5.60 m² |
| Total Separation Surface |
7.36 m² |
| Stone Trap |
Yes |
Cleaning System |
|---|
| Total Ventilated Sieve Area |
5.28 m² |
| Fan Type |
Crossflow |
Grain Tank |
|---|
| Capacity |
8500 liters |
| Unloading/Discharge Speed |
90 l/sec. |
| Tube/Pipe Length |
5.00, 5.60 and 6.00 m |
Header |
|---|
| Header Option |
Yes |
| Cutting Frequency |
1220 cuts/min |
| Cutting Width |
4.20 m – 4.80 m– 5.40 m– 6.30m |
| Varicrop Cutting Width |
5.00 m – 5.50 m – 6.50 – 7.50 m |
Tires |
|---|
| Front Tire |
650/75 R32 |
| Rear Tire |
405/70 R20 |
Transmission |
|---|
| Type |
Hydrostatic |
| Gear |
4 forward |
| Speed |
0-26 km/h |
| Brake |
Hydraulic |
Refill Capacities |
|---|
| Fuel Tank Capacity |
750 liters |
| AdBlue® Capacity |
76 liters |
Cabin |
|---|
| Cab Type |
Commander Cab V |
| Seat |
Adjustable |
| Display |
Yes |
| Camera |
Yes |
| Lights |
Yes |
